Obs169 | More Powerful Tab Display Plugins: Tabs and Tab-panels

Previously, in Obs143｜Using Tabbed Interfaces: The HTML Tabs Plugin; Enhancing Presentation Convenience in Obsidian, I demonstrated how to use the HTML Tabs plugin to create tabbed sections within notes. Today, we'll look at the more feature-rich obsidian-tabs plugin and the comparatively simpler Tab-Panels.

1. Tabs

Use a code block with the language set to tabs, i.e., ```tabs.
The first line can specify display styles:
- Tab position: top, bottom, left, right
- Tab row count: one, multi
Double-click the tab content to open an edit window.
Includes a "Convert selected text to tabs" command.

top, multi
tab: 🔢 LaTex Math Expressions
Formula example
$$
 \begin{cases}
 a_1x+b_1y+c_1z=d_1\\
 a_2x+b_2y+c_2z=d_2\\
 a_3x+b_3y+c_3z=d_3\\
 \end{cases}
 $$
tab: 🖼️ Image<br>Second line description
Embed image

![gh|700](https://raw.githubusercontent.com/emisjerry/upgit/master/2024/1729215597000xfh5k3.png)
tab: HTML
```HTML
<html>
<head>
  <script src="test.js"></script>
  <link rel="stylesheet" href="mystyle.css">
</head>
<body>
  <div class="note">
  My Note
  </div>
</body>
<script>
  test();
</script>
</html>
```

tab: CSS
```css
body {
  color: red;
  background-color: lightYellow;
}
```

tab: Tab 5
Tab 5 content
tab: Tab 6
Tab 6 content
tab: Tab 7
Tab 7 content
tab: Tab 8
Tab 8 content
tab: Tab 9
Tab 9 content
tab: Tab 10
Tab 10 content
tab: Tab 11
Tab 11 content
tab: Tab 12
Tab 12 content

An image to describe post

1.1. Differences from HTML Tabs

---tab JavaScript is changed to tab: JavaScript.
Tabs: The initial ~~~tabs can still be used, or it can be changed to ```tabs`.

tab: 🛜HTML
```html file:test.html ln:true
<html>
<head>
  <script src="test.js"></script>
  <link rel="stylesheet" href="mystyle.css">
</head>
<body>
  <div class="note">
  My Note
  </div>
</body>
<script>
  test();
</script>
</html>
```
tab: 🖼️CSS
```css file:mystyle.css ln:true
body {
  color: red;
  background-color: lightYellow;
}
```
tab: 🧑‍💻JavaScript
```js file:test.js ln:true
<script>
  function test() {
    alert("Hello!");
  }
</script>
```

Codeblock Customizer Integration

Remember to add tabs to the Basic → Exclude languages list.

2. Tab Panels

Use a code block with the language set to tab-panels, i.e., ```tab-panels.
Each tab format: --- Tab Title
Tab titles cannot contain HTML tags.

--- First Tab
Formula example
$$
 \begin{cases}
 a_1x+b_1y+c_1z=d_1\\
 a_2x+b_2y+c_2z=d_2\\
 a_3x+b_3y+c_3z=d_3\\
 \end{cases}
 $$

--- 🖼️ Image<br>Second line description
Embed image

![gh|700](https://raw.githubusercontent.com/emisjerry/upgit/master/2024/1729215597000xfh5k3.png)

--- HTML
```html
<html>
<head>
  <script src="test.js"></script>
  <link rel="stylesheet" href="mystyle.css">
</head>
<body>
  <div class="note">
  My Note
  </div>
</body>
<script>
  test();
</script>
</html>
```

--- CSS
```css
body {
  color: red;
  background-color: lightYellow;
}
```

--- Tab 5
Tab 5 content

--- Tab 6
Tab 6 content

--- Tab 7
Tab 7 content

--- Tab 8
Tab 8 content

An image to describe post
